TIGITAL® 3D-Print SLS Materials

PPP-Series

TIGITAL® 3D-Print Series PPP (Premium Performance Polymers) stand out due to excellent flame retardant properties.

TIGITAL® 3D-Print Series PPP (Premium Performance Polymers)  fulfill international standards according to UL94-V0, DIN EN 45545 R22 - HL1, 2 &3, UN ECE R118 for a variety of applications in public transportation.

Benefits:

  • Superior flame retardancy

  • Usable on all open SLS printing machines

  • User friendly printing parameters

  • Very high re-use rate (>70%)

  • High stiffness and dimensional accuracy


Applications:

  • Tram

  • Subway

  • Rail

  • Bus



Download Technical Information Sheet

Flame Retardancy
High Stiffness
Versatile
High Reuse Rate
SLS 3D Printing Materials for Public Transportation Industry
TIGITAL® 3D-Set Series TPP (Top Performance Polymers) stand out due to excellent UV resistance and high stiffness.

TPP-Series

TIGITAL® 3D-Print Series TPP (Top Performance Polymers) stand out due to excellent UV resistance and high stiffness.

TIGITAL® 3D-Print Series TPP (Top Performance Polymers) are printable at vastly lower printing temperatures than standard printing materials. TPP materials have great electrical insulating properties and very low moisture uptake.

Benefits

  • Usable on all open SLS printing machines
  • User friendly printing parameters
  • Very high re-use rate (>70%)
  • High UV-stability
  • Minimal moisture uptake (<1%)


Applications

  • Transportation
  • Outdoor
  • Aerospace and Defense
  • Electronics
High Reuse Rate
Min. Moisture Uptake
Versatile
UV Stability

HPP-Series

TIGITAL® 3D-Print Series HPP (High Performance Polymers) show very accurate and excellent dimension stability.

TIGITAL® 3D-Print Series HPP (High Performance Polymers) have very low shrinkage even at very high wall thicknesses. It exhibits superior rigidity and is easy to print with vastly lower printing temperatures than standard printing materials on all SLS devices.

Benefits

  • High reuse-rate
  • Vastly lower printing temperatures
  • Ability to print high wall thickness (>10mm)
  • Superior rigidity
  • Minimal moisture uptake (<1%)


Applications

  • Bus and Rail
  • Automotive
  • Aerospace and Defense
  • Prototyping
Enhanced Printing
Low Print. Temperature
High Rigidity
High Reuse Rate
TIGITAL® 3D-Set Series HPP (High Performance Polymers) show very accurate and excellent dimension stability.

Material Comparison Table:


Material

HPP
370/80003

TPP
371/80005

TPP
371/80006

PPP
371/80002

PPP
371/80004

PPP
371/80008

Density [kg/m3]
1310
1320
1310
1250
1250
1570

Modulus [MPa]


3300

3000
3200
2100
3200
4000

Strength [MPa]
52

45
50
40
40
38

Strain [%]
2.5

6
6
5.5
2.1
1.5

HDT-A [°C]
65

-
60
-
80
60

Color
Black
Black
Black
Black
Black
Black

Features
-
UV
FLEX


UN ECE R 118 03
Annex 6, 7 & 8

UL 94 - V0


DIN EN 45545
R22 - HL 1,2,3
